VINACNC - Expert in High-Precision Custom CNC Machining of Graphite Jigs for Electronic Component Packaging

In the semiconductor and electronics industries, the packaging of sensitive components requires extremely high precision and heat resistance to ensure the quality of the final product. VINACNC is proud to offer a specialized custom graphite jig manufacturing service, designed to meet the most stringent requirements of the electronic component packaging process.

Technical Specifications, Materials, and Applications

• Material: The products are crafted from high-purity graphite. This material stands out for its exceptional heat resistance, chemical corrosion resistance, and non-reactive nature with encapsulation materials, which helps maintain the integrity of the components during the packaging process.

• Technical Properties:

  • Heat Resistance: Graphite can withstand temperatures of over 3000°C, making it ideal for high-temperature processes such as welding, sintering, or heat treatment.

  • High Precision: The jigs are CNC machined to achieve precise tolerances, ensuring that the components are perfectly positioned and held securely throughout the packaging process.

  • Smooth Surface: Graphite has a naturally smooth surface, which allows parts to be easily released from the jig without damage.

• Applications: Graphite jigs are widely used for:

  • Positioning and Holding Components: Securing electronic components, semiconductor chips, or other sensitive parts during encapsulation and packaging.

  • Electronic Component Manufacturing: Used in sintering furnaces, vacuum furnaces, and other production equipment.

Product Advantages

• High Precision: Thanks to CNC machining, our fixtures have absolute dimensional accuracy, facilitating high-precision mass production.

• Heat and Corrosion Resistance: The extremely high heat and corrosion resistance of graphite ensures a long jig lifespan and allows for multiple reuses.

• Chemical Inertness: Graphite is an inert material that does not react with the packaging material, ensuring the quality and integrity of the final product.

• Optimized Costs: The long lifespan and high production efficiency of our jigs help minimize investment and operational costs for our clients.

Post-Machining Product Inspection Process

1. Dimensional Inspection: We use digital calipers and other precision measuring tools to verify the dimensions of the graphite jig against the technical drawings.

2. Surface Finish Inspection: We conduct visual inspections and use specialized measuring devices to ensure the surface meets the requirements and is free of cracks or defects.

3. Functional Test: A trial run is performed by fitting the parts to be processed onto the jig to ensure perfect positioning and secure holding.

Packaging and Storage Process

• Cleaning: The jig is thoroughly cleaned to remove carbon dust and other impurities.

• Careful Packaging: The product is packed in a sturdy cardboard box or a wooden crate with foam to prevent impact and chipping during transport.

• Labeling and Instructions: The packaging is clearly labeled with product information, including the product code, dimensions, and usage/storage instructions.

• Storage: We recommend storing the jig in a dry, cool environment, away from heavy impacts, to maintain its best quality.
