All-in-One Solution: Custom-made Punch Dies for Accurate Metal Stamping

The detail information of product

VINACNC - Expert in High-Precision Custom Punch and Die Tools

In the mold and stamping industry, punch pins and punch dies are core components that determine the precision and efficiency of the production process. VINACNC is proud to offer a manufacturing service for high-quality, custom-made punch and die tools with a flat design, at a competitive price. We meet the most stringent standards of the precision parts manufacturing industry.

Technical Specifications, Materials, and Applications

Materials: The products are crafted from high-quality tool steels such as SKD-11, M2, and HSS. These materials are known for their high hardness, wear resistance, and toughness after heat treatment.
Technical Properties:
- Custom Design: We specialize in creating custom-made designs for punch pins and dies, ensuring they are perfectly tailored to your specific application.
- Punching Die: Used for cutting and punching holes in materials.
- Hardness: After heat treatment, the material achieves a stable hardness (typically HRC 58-62°), allowing the components to withstand high pressure and friction during continuous operation.
- Precision: Products are CNC machined with extremely tight tolerances, ensuring a perfect fit between the punch and die, which helps to create parts with precise dimensions.
Applications: Our components are indispensable parts of stamping dies for cutting and punching holes in sheet metal or plastic parts. They are widely used in industries producing automotive parts, electronic device housings, and precision machinery.

Product and Service Advantages

Superior Durability: With high-quality steel materials, the components resist repetitive force and pressure, significantly extending the mould's lifespan.
Absolute Precision: Dimensions and shapes are strictly controlled down to the micrometer level, ensuring the final product is of the highest quality.
Optimized Performance: The smooth operation helps to reduce the stamping cycle time and enhances overall production efficiency.
Flexible Customization: We provide a custom manufacturing service from design to machining, ensuring the product perfectly matches the client's blueprints and intended use.

Quality Inspection Process

Hardness Test: We use a professional hardness tester to verify the hardness of the heat-treated material.
Dimensional and Tolerance Check: We use a Coordinate Measuring Machine (CMM) to verify all critical dimensions and tolerances against the technical drawings.
Surface Inspection: We perform visual inspections and use specialized measuring devices to ensure the surface meets requirements, with no cracks or defects.
Functional Test: Components are test-fitted with related parts to ensure a perfect fit and smooth operation.

Packaging and Storage Process

Cleaning and Rust Prevention: The components are cleaned and coated with a specialized anti-rust oil.
Secure Packaging: Products are carefully packed in rigid plastic boxes or cardboard crates with foam to prevent damage during transport.
Information Labeling: The packaging is clearly labeled with product information, including the product code, dimensions, and handling instructions.
Storage Instructions: We recommend storing the products in a dry, cool environment, away from high humidity and corrosive chemicals.
