VINACNC - Expert in High-Precision Custom Metal Punch Die Assembly

In the die and mould industry, punch pins and punch dies are core components that determine the precision and efficiency of the production process. VINACNC is proud to offer a manufacturing service for high-quality custom punch die assemblies at a competitive price, meeting the most stringent standards of the precision parts manufacturing industry.

Technical Specifications, Materials, and Applications

Materials: Our products are crafted from high-quality tool steels such as SKD-11, M2, HSS, or other materials as required. These materials are known for their high hardness, wear resistance, and toughness after heat treatment.
Technical Properties:
- Square Punch and Die: The special square head design of the punch allows for precise positioning and concentrated punching force, making it suitable for stamping dies and punching machines.
- Hardness: After heat treatment, the material achieves a stable hardness (typically HRC 58-62°), allowing the components to withstand high pressure and friction during continuous operation.
- Precision: Products are CNC machined with extremely tight tolerances, ensuring a perfect fit with the die and helping to create parts with precise dimensions.
Applications: Our components are indispensable for stamping dies used to cut and punch holes in sheet metal or plastic parts. They are widely used in the manufacturing of household appliances, automotive parts, and precision machinery.

Product and Service Advantages

Superior Durability: With high-quality steel materials, our tools resist repetitive force and pressure, significantly extending the mould's lifespan.
Absolute Precision: Dimensions and shapes are strictly controlled down to the micrometre level, ensuring the final product is of the highest quality.
Optimized Performance: The smooth operation helps to reduce the punching cycle time and enhances overall production efficiency.
Flexible Customization: We provide a custom manufacturing service, from design to machining, ensuring the product perfectly matches the client's blueprints and intended use.

Quality Inspection Process

Hardness Test: We use a professional hardness tester to verify the hardness of the heat-treated material.
Dimensional and Tolerance Check: We use a Coordinate Measuring Machine (CMM) to verify all critical dimensions and tolerances against the technical drawings.
Surface Inspection: We perform visual inspections and use specialized measuring devices to ensure the surface meets requirements, with no cracks or defects.
Functional Test: Components are test-fitted with related parts to ensure a perfect fit and smooth operation.

Packaging and Storage Process

Cleaning and Rust Prevention: The components are cleaned and coated with a specialized anti-rust oil to protect their precision surfaces.
Secure Packaging: Products are carefully packed in rigid plastic boxes or cardboard crates with foam to prevent damage during transport.
Information Labeling: The packaging is clearly labeled with product information, including the product code, dimensions, and handling instructions.
Storage Instructions: We recommend storing the products in a dry, cool environment, away from high humidity and corrosive chemicals.
