VINACNC - Expert in Precision Manual Hydraulic Punch Dies

In the mold and stamping industry, punch dies are core components that determine the precision and efficiency of the production process. VINACNC is proud to offer a manufacturing service for manual hydraulic punching press brake mould sets with high quality and competitive prices, meeting the most stringent standards of the sheet metal processing industry.

Technical Specifications, Materials, and Applications

• Material: The products are crafted from high-quality tool steels such as SKD-11, M2, and HSS. These materials are known for their high hardness, wear resistance, and good toughness after heat treatment.

• Technical Properties:

  • Hydraulic System: The mold set is designed to work efficiently on manual hydraulic punching presses, ensuring powerful and precise punching force.

  • High Precision: Products are CNC machined with extremely tight tolerances, ensuring a perfect fit between the punch and die, which helps to create parts with precise and uniform dimensions.

  • Surface Finish: The surface is specially treated to achieve high smoothness, which reduces friction and extends the lifespan of the punch and die.

• Applications: Our components are indispensable parts of stamping dies for cutting and punching holes in sheet metal parts, including aluminum and steel. They are widely used in industries producing equipment enclosures, automotive parts, and precision machinery.

Product Advantages

• Superior Durability: With high-quality steel materials, the components resist repetitive force and pressure, significantly extending the mold's lifespan.

• Absolute Precision: Dimensions are strictly controlled down to the micrometre level, ensuring the components operate in perfect conjunction, minimizing the risk of product defects.

• Optimized Performance: The smooth operation helps to reduce the cycle time and enhances overall production efficiency.

• Competitive Pricing: Thanks to our optimized and efficient production process, we can offer products at a very competitive price.

Post-Machining Product Inspection Process

1. Hardness Test: We use a professional hardness tester to verify the hardness of the heat-treated material.

2. Dimensional and Tolerance Check: We use a Coordinate Measuring Machine (CMM) to verify all critical dimensions and tolerances against the technical drawings.

3. Surface Inspection: We use a surface roughness tester and visual inspection to ensure there are no cracks, scratches, or other defects.

4. Functional Test: The components are test-fitted with related parts to ensure a perfect fit and smooth operation.

Packaging and Storage Process

• Cleaning and Rust Prevention: The punch and dies are cleaned and coated with a specialized anti-rust oil to protect their precision surfaces.

• Secure Packaging: Products are carefully packed in rigid plastic boxes or cardboard crates with foam to prevent damage during transport.

• Information Labeling: The packaging is clearly labeled with product information, including the product code, dimensions, and handling instructions.

• Storage Instructions: We recommend storing the products in a dry, cool environment, away from high humidity and corrosive chemicals.
