VINACNC - Expert in High-Precision MISUMI Standard Carbide Punch Pins and Dies

In the mould and stamping industry, punch pins and punch dies are core components that determine the precision and efficiency of the production process. VINACNC is proud to offer a manufacturing service for high-quality MISUMI standard carbide punch pins and dies that are meticulously polished and meet international standards. We are committed to providing durable, precise, and high-performance mould components.

Technical Specifications, Materials, and Applications

Material: The products are crafted from carbide (hard alloy), a material known for its exceptional hardness, wear resistance, and high durability. Carbide is an ideal choice for applications subjected to heavy loads and high friction.
Standards:
- MISUMI: Our punch pins and dies are manufactured according to the international standard of MISUMI, ensuring high compatibility and quality, which makes them easy to replace and integrate into existing moulds.
Technical Properties:
- Hardness: Carbide material achieves an extremely high hardness (typically above HRC 65°), enabling the pins to withstand high pressure and friction during continuous operation.
- Precision: The products are CNC machined with extremely tight diameter tolerances, ensuring a perfect fit with the die and helping to create parts with precise dimensions.
- Surface Finish: The surface is specially treated to achieve a high-quality polished finish, which minimizes friction and extends the lifespan of the tool.
Applications: Our components are indispensable parts of stamping dies for cutting and punching holes in sheet metal or plastic parts. They are also used in extrusion moulds and are widely utilized in industries producing automotive parts, electronic device housings, and precision machinery.

Product Advantages

Superior Durability: With high-quality carbide material, the components resist repetitive force and pressure, significantly extending the mould's lifespan.
Absolute Precision: Dimensions are strictly controlled down to the micrometre level, ensuring the components operate in perfect conjunction and minimizing the risk of product defects.
Optimized Performance: The smooth, polished surface helps to reduce the stamping cycle time and enhances overall production efficiency.
International Standard Compliance: Manufacturing according to the MISUMI standard ensures high compatibility and quality, making it easier for clients to integrate our components into their existing systems.

Post-Machining Product Inspection Process

Hardness Test: We use a professional hardness tester to verify the hardness of the material, ensuring it meets technical specifications.
Dimensional and Tolerance Check: We use a Coordinate Measuring Machine (CMM) to verify all critical dimensions and tolerances against the technical drawings.
Surface Inspection: We use a surface roughness tester and visual inspection to ensure there are no cracks, scratches, or other defects.
Functional Test: The components are test-fitted with related parts to ensure a perfect fit and smooth operation.

Packaging and Storage Process

Cleaning and Rust Prevention: The components are cleaned and coated with a specialized anti-rust oil to protect their precision surfaces.
Secure Packaging: Products are carefully packed in rigid plastic boxes or cardboard crates with foam to prevent damage during transport.
Information Labeling: The packaging is clearly labeled with product information, including the product code, dimensions, and handling instructions.
Storage Instructions: We recommend storing the products in a dry, cool environment, away from high humidity and corrosive chemicals.
