High-Quality Dayton Standard Punch Dies for Metal & Plastic Moulding

The detail information of product

VINACNC - Expert in High-Precision Dayton Standard Punch Dies for Metal and PC

In the mold industry, the punch pin (punch dies) is a core component that determines the precision and efficiency of the stamping process. VINACNC is proud to supply Dayton Standard punch dies with high hardness and tight tolerances, ensuring superior performance and durability even under harsh production conditions.

Technical Specifications, Materials, and Applications

Materials: The products are crafted from high-quality tool steels such as SKD-11, M2, or other materials that comply with the Dayton Standard. These materials are known for their high hardness, wear resistance, and good toughness after heat treatment.
Technical Properties:
- Dayton Standard: Products conform to the technical specifications and quality standards of Dayton, a renowned brand in the stamping die industry, ensuring compatibility and reliability.
- Hardness: After heat treatment, the material achieves a stable hardness (typically HRC 58-62°), allowing the punch pins to withstand high pressure and friction during continuous operation.
- Precision: The products are machined with extremely tight diameter tolerances, ensuring a perfect fit with the die and helping to create parts with precise dimensions.
Applications: Dayton Standard punch dies are indispensable components in stamping dies for cutting and punching holes in sheet metal or plastic (PC) parts.

Product Advantages

Superior Durability: With high-quality materials, the punch pin resists repetitive force and pressure during production, extending the mould's lifespan.
Absolute Precision: Dimensions are strictly controlled down to the micrometre level, ensuring the components operate in perfect conjunction, minimizing the risk of product defects.
Optimized Performance: The smooth operation helps to reduce the stamping cycle time and enhances overall production efficiency.
International Standard Compliance: Manufacturing according to the Dayton Standard ensures compatibility and high quality, making it easier for clients to integrate our components.

Post-Machining Product Inspection Process

Hardness Test: We use a professional hardness tester to verify the hardness of the heat-treated material, ensuring it meets technical specifications.
Dimensional and Tolerance Check: We use a Coordinate Measuring Machine (CMM) or other high-precision measuring instruments to check the diameter, length, and concentricity.
Surface Inspection: We use a surface roughness tester and visual inspection to ensure there are no cracks, scratches, or other defects.
Functionality Test: The components are test-fitted with related parts to ensure a perfect fit and smooth operation.

Packaging and Storage Process

Cleaning and Rust Prevention: The punch pin is cleaned and coated with a specialized anti-rust oil to protect its precision surfaces.
Secure Packaging: The product is carefully packed in a rigid plastic box or a cardboard crate with foam to prevent damage during transport.
Information Labeling: The packaging is clearly labeled with the product code, weight, dimensions, and handling instructions.
Storage Instructions: We recommend storing the product in a dry, cool environment, away from high humidity and corrosive chemicals.
